ERVOR G06 - Page 41

Page 41
Manual G06
Edition: 10/2015 - rev A
ERVOR (SCA) - 6, Rue Désiré Granet - Z.I. du Val d'Argent - 95100 ARGENTEUIL FRANCE
 (33) 01 34 11 50 00  (33) 01 34 11 50 10
Web : www.ervor.com - Email : info@ervor.com
!
TO ORDER SPARE PARTS, SEE CHAPTER 12.
ILLUSTRATION N° 3
ITEM QUANTITY DESCRIPTION
SPARE PARTS
REFERENCE
REFERENCE
001A 8 Soc.hd.cap screw M8 x 40 7 402 042
010A 1 Soc.hd.cap screw M8 x 20 7 402 038
020A 1 Connection 1/2" pipe Ø18 8 141 513 7 661 008
030A 1 Low pressure manifold 3 934 029 3 934 029
040A 2 Air filter 8 200 000 8 200 000
-
050A 1 Connection M 1/8" x Ø6 for rilsan 4x6 8 970 180 7 661 008
060A 1 LP manifold gasket 8 970 174 7 500 319
070A 4 Split pin 8 970 177 7 436 004
080A 8 Belleville washer 8 970 177 7 421 009
090A 4 Castellated nut 8 970 177 3 933 024
100A 2 Low pressure compression stop 8 970 177 3 936 020
110A
10
Valve spring Ø35 8 970 177 3 933 013
120A 4 Low pressure valve Ø35 8 970 177
3 933 042
130A 1 Low pressure cylinder head 8 970 178 3 932 007
140A 2 Low pressure intake stop 8 970 177 3 936 010
150A 6 Valve stem 8 970 177 3 925 002
160A 1 Low pressure cylinder head gasket 8 970 174 7 500 216
170A 4 Soc.hd.cap screw M10 x 30 7 402 002
180A 1 High pressure cylinder (standard version) 3 931 011 3 931 011
180B 1 High pressure cylinder (Llyod's version) 3 931 023 3 931 023
180C 1 High pressure cylinder (Bureau Veritas) 3 931 015 3 931 015
190A 1 Cylinder gasket 8 970 174 7 500 102
200A 4 Crinkle washer M10 7 421 001
-
210A 1 Soc.hd.cap screw M8 x 20 7 402 038
(
-
) this part is not illustrated
