Page 43
Manual G06
Edition: 10/2015 - rev A
ERVOR (SCA) - 6, Rue Désiré Granet - Z.I. du Val d'Argent - 95100 ARGENTEUIL FRANCE
(33) 01 34 11 50 00 (33) 01 34 11 50 10
Web : www.ervor.com - Email : info@ervor.com
!
TO ORDER SPARE PARTS, SEE CHAPTER 12.
ILLUSTRATION N° 4
ITEM QUANTITY DESCRIPTION
SPARE PARTS
REFERENCE
001A 1 Hex.hd.machine screw M10 x 25
010A 2 Washer
020A 1 Fan 3 050 006
030A 1 Internal fixing lugs of fan cowling 8 960 051
040A 4 Soc.hd.cap screw M8 x 25
050A 4 Crinkle washer M8
060A 2 Bearing 7 520 020
-
070A 2 Bearing housing gasket 8 970 174
080A 1 Casing 3 930 014
080B 1 Casing (ref: 3 930 018) with
3 930 018
oil level switch (ref: 7 710 024)
090A 2 Oil sight glass 1" 7 233 006
-
100A 2 Oil discharge plug 7 603 017
110A 2 Woodruff key 8 920 011
120A 1 Cranckshaft 8 920 011
130A 2 Counterweight 8 920 011
140A 2 Ø6 Slotted spr.pin 8 920 011
150A 1 Spacer 3 921 011
-
160A 1 Ø 72 Internal Circlip
170A 1 Read bearing housing 3 936 011
180A 4 Soc.hd.cap screw M8 x 25
190A 4 Crinkle washer M8
200A 2 Ø 30 Internal Circlip 8 923 004
210A 1 Piston shaft 8 923 004
220A 1 Connecting rod 8 922 006
230A 1 Projector 8 922 006
240A 1 Hex.hd.machine screw M8 x 20
250A 2 Anti-leak ring Ø 125 8 970 089
260A 2 Scraper ring Ø 125 8 970 089
270A 1 Monobloc piston 8 823 004
280A 1 Scraper ring Ø 50 8 970 089
290A 3 Anti leak ring Ø 50 8 970 089
300A 1 Front bearing housing 3 936 017
(
-
) This part is not illustrated
