CutSkill 60
OPERATING MANUAL
INTRODUCTION 2-2 0-5574
A-13882
15.8kg
437
176
290
324
Figure 2-1: Power Supply Dimensions & Weight
NOTE
Weight includes torch & leads, input power cord, and work cable with clamp.
!
CAUTION
Provide clearance for proper air ow through the power supply. Operation without proper air ow will inhibit proper cooling
and reduce duty cycle..
2.03 Generator Recommendation
When using generators to power the Plasma Cutting System, the following ratings are a minimum and are to be used along
with the ratings listed above.
Model Generator Output Rating
CutSkill 60 15 kVA
Table 2-2: Generator Recommendation
2.04 Circuit Breaker Recommendation
Model Circuit Breaker Rating
CutSkill 60 25A, Type C
Table 2-3: Circuit Breaker Recommendation
