CutSkill 60
OPERATING MANUAL
SERVICE 5-2 0-5574
A. Every three months
Check external air filter, replace if necessary.
1. Shut off input power; turn off the gas supply. Bleed down the gas supply. Check air filter and replace if neces-
sary.
NOTE
Leave internal ground wire in place
B. Every six months
1. Check the in-line air filter(s), clean or replace as required.
2. Check cables and hoses for leaks or cracks, replace if necessary.
3. Vacuum dust and dirt out of the entire machine.
5.02 Basic Troubleshooting Guide
!
WARNING
There are extremely dangerous voltage and power levels present inside this unit. Do not attempt to diagnose or repair it un-
less you are an accredited service provider and you have had training in power electronics measurement and troubleshooting
techniques.
PROBLEM CAUSE REMEDY
1 LCD screen is not
illuminated.
A Main input power cord does
not connect to power socket.
A Connect the power cord.
B Power ON/OFF switch in OFF
(down) position.
B Turn switch to ON (up) position.
C Actual input voltage does not
correspond to required 240V of
the unit.
C Ensure that the mains supply is
within 240VAC +/- 15% then turn
the power source OFF then turn the
power source back ON.
D Faulty components in unit D Have an accredited CIGWELD
service provider repair or replace
2 Torch or shield cup
installation error
A Torch is not correctly
connected to the power source.
A Reinstall torch, make sure torch
has fully installed into the plasma
cutting torch female adaptor,
and screw the plastic torch nut
clockwise to secure in position.
B Shield cup is not installed
correctly.
B Install the shield cup again.
C Plasma torch failure C Have an accredited CIGWELD
service provider repair or replace.
3 Air pressure error A Input air pressure too low or
too high
A Adjust the input air pressure to
600kPa~800Kpa.
B Gas passage contains
impurities.
B Disconnect gas hose from the rear
of power source or wirefeeder and
blow out impurities.
C Gas leakage C Check gas leakage between the gas
gose and the gas inlet or cylinder
outlet.
D Faulty component in unit. D Have an accredited CIGWELD
service provider repair or replace.
To Next Page
