ESAB CIGWELD CutSkill 60 - Torch Connection

CutSkill 60
OPERATING MANUAL
INSTALLATION 3-6 0-5574
3.06 Torch Connection
Fit the CutSkill 60A plasma torch to the power source by pushing the male torch connector into the female
torch adaptor and screwing the torch locking nut clockwise to secure the plasma torch to the torch adaptor.
CutSkill 60A Plasma Torch
A-13884
Figure 3-5: Connecting Plasma Torch
