ESAB ES 150i - Service Preparation and Tools; Recommended Service Aids and Tools

BEFORE STARTING SERVICE
0463 714 001
- 6 -
© ESAB AB 2020
BEFORE STARTING SERVICE
NOTE!
Follow the instructions in chapter "IN-SERVICE INSPECTION AND TESTING",
page55 when performing service work on the equipment!
Service aid
ESAB can offer a number of service tools that will simplify the service.
Antistatic service kit
Ordering no. 0740 511 001
The kit makes it easier to protect sensitive
components from electrostatic discharge.
Contents:
• A conductive mat (size 610×610mm /
24×24in.)
• A 1.5m (3.28ft) long ground cable with
a crocodile clip
• An adjustable wrist strap and cable with
a built-in protective resistor
ESAB tools
Tool Ordering number
ESAB test box TB1 0460 868 880
Checkmaster 9000
Checkmaster 9000 DC
Or resistive load with equal performance
Recommended measuring devices
• For safety test: Fluke 1503, Fluke 1507, Fluke 1577 and Fluke 1587.
• For measurements: Fluke 175, Fluke 177 and Fluke 179.
