6 CONTROL PANEL
0463 930 001
- 26 -
© ESAB AB 2023
6.4 Menu selection
6.4.1 MIG/MAG and MIG/MAG SYN
In MIG mode, press the parameter selection button three times to navigate to MENU option. Select the
desired welding function one after other by turning the left potentiometer knob and adjust the desired
value by turning the right potentiometer knob.
Left diplay letter Function Default Right display settings
B-B Burnback 0.1 0.01-0.35
CRA Crater fill time 0 0.0-9.9
PRG Pre-flow 0.1 0.5-9.9
POG Post-flow 0.5 0.5-9.9
RIN Creep start (Run in) ON ON/OFF
Burnback (B-B)
Burnback time is a delay between the time when the wire starts to brake until the time when the
power source switches off the welding voltage.
Too short burnback time results in a long wire stick out after completion of welding, with a risk of the
wire being caught in the solidifying weld pool.
Too long a burnback time results in a shorter stick out, with increased risk of the arc striking back to
the contact tip.
Crater fill (CRA)
Crater filling makes a controlled reduction in the heat and size of the weld pool possible when
completing the weld. This makes it easier to avoid pores, thermal cracking and crater formation in the
weld joint.
Pre/flow (PRG)
Pre-flow controls the time during which shielding gas flows before the arc is struck.
Post/flow (POG)
This controls the time during which shielding gas flows after the arc is extinguished.
Creep start (RIN)
Creep start feeds out the wire at a low wire feed speed until it makes electrical contact with the
workpiece.
6.4.2 Hidden functions for MIG/MAG and MIG/MAG SYN
Long press the parameter selection button to navigate the hidden MENU option (No welding). Select
the desired function one after the other by turning the left potentiometer knob and adjust the value by
turning the right potentiometer knob.
Left diplay letter Function Default Right display settings
DIS Display value druing
welding
WFS WFS/AMP
SYN Workpoint in synergic WFS WFS/THI
UNT Unit (metric or imperial) MPM MPM/IPM
TJS Trigger job select OFF ON/OFF
