Left diplay letter Function Default Right display settings
VEN Version no. V4.0 -
RES Default settings No No/Yes
Display (DIS)
This function enables to display of the wire feed speed (WFS) or amperage (AMP) values during
welding.
Synergic (SYN)
This function enables to set up a machine work point based on wire feed speed (WFS) or material
thickness (THI).
Unit (UNT)
This function enables switching the units of measure for wire feed speed and thickness between the
metric (MPM) or imperial (IPM).
Trigger job (TJS)
This function permits changing between different welding data memories by pressing the trigger of
the welding torch. Pressing the trigger once will activate Job 1 and pressing the trigger twice will
activate Job The same procedure should be followed for all the Jobs.
Version No. (VEN)
This function enables viewing the software versions of the connected system.
Reset (RES)
This function resets to the factory default settings. All saved jobs will be deleted as a result of the
reset.
6.4.3 MIG SPOT
In MIG SPOT mode, press the parameter selection button three times to navigate to the MENU option.
Select the desired welding function one after the other by turning the left potentiometer knob and
adjusting the value by turning the right potentiometer knob.
Left diplay letter Function Default Right display settings
B-B Burnback 0.1 0.01-0.35
S/T Spot time 0.1 0.1-5.0
DWE Rest time 0.1 OFF/0.1-5.0
POG Post-flow 0.5 0.5-9.9
Burnback (B-B)
Burnback time is a delay between the time when the wire starts to brake until the time when the
power source switches off the welding voltage.
Too short burnback time results in a long wire stick out after completion of welding, with a risk of the
wire being caught in the solidifying weld pool.
Too long a burnback time results in a shorter stick out, with increased risk of the arc striking back to
the contact tip.
Spot Time (S/T)
Spot time is a time when the arc will be enabled after pressing the trigger.
Rest time (DWE)
Rest time is used to define time without arc between spot welds.
