6  CONTROL PANEL
0463 930 001
- 21 -
© ESAB AB 2023
MENU
There are basic functions in the menu feature. To access the functions,
press the parameter selection button until the MENU symbol is ON. The left
display shows a letter and the right display shows a value. Select the
function by pressing the same button. The knob (4) is used to change the
value of the selected function. The knob (3) is used to change the different
functions.
NOTE!
The list of MENU functions will vary depending on the application
selected.
Left potentiometer knob (3)
In MIG (GMAW/FCAW) mode, the knob is used to adjust the output voltage of the unit. In Manual
MIG Mode, the setup chart is attached to the Wirefeeder compartment door.
In MIG SYN mode (EM350CPROSYNERGIC) turning the knob will select the TRIM function. In
TRIM function, the knob clockwise increases the voltage by 0.1V increments and the maximum value
is +5V.
In the Parameter selection state, adjusting the left knob (3) will select the different feature and the
name will shows on the left LED.
Right potentiometer knob (4)
The right knob (4) adjusts the amount of welding current delivered by the power source. In MMA
modes, the knob directly adjusts the power inverter to deliver the desired level of output current.
In MIG (GMAW/FCAW) mode, the right knob adjusts the speed of the wire feed motor. The optimum
Wire feed speed required will be dependent on the type of welding application. the setup chart is
attached to the Wirefeeder compartment door.
In MIG SYN mode (EM350CPROSYNERGIC) turning the right Knob will select wire feed speed or
thickness. The default value will be wire feed speed and thickness can be selected in the hidden
functions.
Jobs (5)
These buttons have five sets of welding dates for the user to load and save. It can be applied for
MIG/ MAG welding.
6.2 LED indicators description
Indicator Description
MIG/MAG
Constant voltage control process is where the set voltage and the wire
feed speed are set independent of each other.
MIG/MAG SYN
A process with synergic voltage and inductance, in relation to wire feed
speed using predetermined synergic line programs providing stable arc
performance. The process operates through short circuit, globular and
spray droplet transfer mode.
