Escea EF5000 - Stainless Steel Fascia Cleaning; Powder Coated Fascia Cleaning

B
A C D E F G SERVICE
10
Option 2: Within a partial enclosure that includes an overhead cover and no more than two walls.
Option 3: Within a partial enclosure that includes an overhead cover and more than two walls, provided
it meets the following conditions:
• At least 25% of the total wall area is completely open, and
• At least 30% of the remaining wall area is open and unrestricted.
C3 Corner Installations
If a cavity is to be created in a corner, the following drawings provide the minimum interior wall
dimensions.
NOTE: Allowances need to be made for cladding the internal parts of the cavity.
1010
855
355
1830
NOTE: Dimensions of the cavity in this diagram represent the internal size only.
