SES 2000 Vac (LS3) AUTOCLAVE Part 3
ST-SM45g Page 31 of 53
PART 3 MAINTENANCE
a Set mains power on/off switch to 'off' (0).
b Press and hold switch SW6 on control PCB (Fig.3.4)
and set mains power on/off switch 'on' (I). Continue
holding switch SW6 until 'MACHINE SET-UP' is
displayed, then release it.
c Make sure that the two fans (one at the rear and one
at the side of the autoclave) are working.
d After a short time 'SES VACUUM 2000?' will be
displayed. Press switch SW1('Yes').
e Display will show 'STANDARD CHAMBER?'. If the
autoclave has a 'Standard' chamber, press SW1
('Yes'). If the autoclave has a 'long' chamber, press
SW2 ('No') and display will change to 'LONG
CHAMBER?'. Press SW1 ('Yes').
f Display will change to 'PRINTER?'. If a printer is
fitted, press SW1 ('Yes'), or if a printer is not fitted,
press SW2 ('No').
NOTE: Do not press SW1 if a printer is not fitted as
this may inhibit special functions, always press
SW2 if a printer is not fitted.
Setting the Autoclave Serial Number (Fig. 3.3)
Note: This procedure is only applicable to units fitted with
a printer.
47 The autoclave serial number (which is on the dataplate
on the inside cover of the autoclave door and on the back
of the autoclave cover) comprises 5 parts:
Prefix letters determined by chamber size
and model
Modification state (A through Z)
Last digit from Year of manufacture
(e.g. 7 = 1997, 0 = 2000)
Month of manufacture (A = Jan, L = Dec).
Serial No comprising two groups: 01 is the
'Hi' group (thousands and hundreds): 23 is
the 'Lo' group (tens and units).
❑ The serial number will be automatically prefixed by
the letters LV or LLV indicating Standard or Long
chamber versions respectively. This is determined
by the set-up procedure in para.48 (d & e).
❑ The modification state is represented by a letter (A
to Z). It is entered into the autoclave as a two digit
code (01 =A, to 26 = Z). Note that on the printout,
the letter will be shown; not the number.
❑ The year of manufacture, which is represented by
the last digit of the year, is entered into the autoclave
as a single number. Thus, if the year is 1996 a '6'
will be indicated. (e.g. 7 = 1997, 0 = 2000).
❑ The month of manufacture is represented by a
single letter (A = January, H = August).
❑ The serial number ('hi00' and 'lo00') which is
represented by four digits, is entered into the
autoclave as two, two-digit groups, 'hi' and 'lo' ('hi' =
thousands and hundreds, 'lo' = tens and units).
Thus, for serial number 0123, 'hi' = 01, 'lo' = 23).
48 Enter the autoclave serial number as follows:
a Check that the display shows 'SET SER NO. ?'.
(i) Press switch SW1 to accept (YES) or switch
SW2 to reject (NO). Pressing switch SW2 will
move the cycle direct to ‘Setting the Cycles in
Use’ mode.
(ii) If SW1 is pressed the display will change to
‘SET MOD LEVEL’. Enter the modification state
(01 = A, to 26 = Z) by pressing switch SW1 to
increase the number, or switch SW2 to decrease
the number.
(iii) When the number is correct, press switch SW3
to accept the entry.
b Check that the display has changed to 'SET BUILD
YEAR'.
(i) Enter the last digit of the year of manufacture (7
= 1997, 0 = 2000) by pressing switch SW1 to
increase the number, or switch SW2 to decrease
the number.
(ii) When the number is correct, press switch SW3
to accept the entry.
c Check that display changes to 'SET BUILD MONTH A'.
(i)
Enter month code (A = January, to L = December)
by pressing switch SW1 to increase the number,
or switch SW2 to decrease the number.
(ii) When the number is correct, press switch SW3
to accept the entry.
d Check that display changes to 'SET SER NO. (HI)00'.
(i) Enter the first two digits of the serial number by
pressing switch SW1 to increase the number, or
switch SW2 to decrease the number.
(ii) When the number is correct, press switch SW3
to accept the entry.
e Check that display changes to 'SET SER NO. (LO)00'.
(i) Enter the last two digits of the serial number by
pressing switch SW1 to increase the number, or
switch SW2 to decrease the number.
(ii) When the number is correct, press switch SW3
to accept the entry.
A H 01235
*
*
5
A
H
0123
