Page 42 of 53 ST-SM45g
PART 4 ILLUSTRATED PARTS LIST
Part 4 SES 2000 Vac (LS3) AUTOCLAVE
PARTS LIST 1: GENERAL SPARES
Item No Part No Description Qty Recommended
Standard Long Per Holding Per Unit
Unit Per Year
1 424117 . Top cover 1 -
2 424168 . Chassis 1 -
* 307267 . . Pipe clamp 1 -
* 111928# . . Screw, self tapping (½") 4 4
3 480301 . . Foot and screw assy 4 -
4 380045 . . Spacer 2 -
* 301136 . . Nut, spire 4 -
* 490202 . . Chamber, support 1 -
* 307223 . . . Washer, shakeproof, M5 5 -
* 307224 . . . Nut, M5 2 -
* 604994 . Label, earth 3 -
5 424169 . Dividing panel 1 -
* 380032 . . Spacer 2 -
6 424204 . Sub-dividing panel 1 -
7 424172 . . PCB support 1 -
8 696643 . . PCB slide 1 -
* 300775 . . Pop Rivets 4 -
9 424109 . Front panel (without printer) 1 -
10 424108 . Front panel (with printer) 1 -
12 . Pressure chamber 1 -
assy (See Parts List 2)
13 490228 490178 . Carrier assy, tray 1 -
* 424392 424393 . . Splash barrier 1 -
* 301409 . . Drip tray 1 -
14 424266 . Reservoir assy 1 -
* 424127 . . Reservoir 1 -
* 424221 . . Drain tube 1 -
* 424165 . . Float sensor 1 1
* 424220 . . Fill pipe 1 -
* 424261 . . Filter 1 1
* 424129 . . Manifold 1 -
* 424128 . . Condensing coil 1 -
15 424191 . Bracket, thermostat manual reset 1 -
* 307249 . . Screw, pan hd, M4 x 8 11 -
* 307163 . . Washer, shakeproof, M4 11 -
16 424233 . Conduit 1 -
* 427005 . Door post 8 -
* 307225 . . Washer, shakeproof, M8 8 -
* 307221 . . Nut, M8 8 -
17 427010 . Door latch 1 -
* 307249 . . Washer, shakeproof, M5 1 -
* 307163 . . Screw, skt hd, cap, M5 2 -
# Was 307137 Screw, self tapping (3/8")
* Not shown Continued
To Next Page
