Page 48 of 53 ST-SM45g
PART 4 ILLUSTRATED PARTS LIST
Part 4 SES 2000 Vac (LS3) AUTOCLAVE
PARTS LIST 3: HEATER AND PROCESS CONTROLS
Item No Part No Description Qty Recommended
Standard Long Per Holding Per Unit
Unit Per Year
13 301127 . Neon, overheat 1 -
14* 490306 . . Neon plate 1 -
* 301862 . . Spacer 7 -
15 380000 . Switch, ON/OFF 1 1
16 424308 . Fan assy 1 -
17 424258 . Support, door lock/fan 1 -
* 710210 . . Screw, soc hd, M4 x 12 4 -
* 696583 . . Grommet 1 -
18 424162 . Fan assy 1 -
* 710129 . . Screw, soc hd, M4 x 16 4 -
* 307163 . . Washer, shakeproof, M4 4 -
19 427035 . Lock, pressure 1 -
* 307218 . . Bolt, M5 x 10 2 -
* 427060 . . Bolt, interlock 1 -
20 424140 . Front panel PCB 1 -
* 301796 . . Spacer 10 -
* 301862 . . Spacer 6 -
21 424138 . Relay board, see Appendix B 1-
* 307152 . . Screw, pan hd, M4 x 6 2 -
* 390371 . . Fuse, F5A, 250V (F4 Pump) 1 1
* 301797 . . Fuse, T2A, 250V (Fan F2) 1 1
* 696207 . . Fuse, T3.15A**, 250V (F1 Txr) 1 1
* 390467# . . Printer lead 1 -
22 424239 . Temperature sensor, band heater 1 1
* 424228 . . Chamber fitting, sensor 1 -
23 424240 . Sensor, chamber temperature 2 1
24 424250 . Sensor pocket 1 -
25 424260 . Spring 1 -
26 424174 . Clamp plate 1 -
* 695776 . Cable tie A/R -
27 424161 . Transformer 1 -
* 424245 . . Strap, securing 1 -
* 424171 . . Nuts, thumb, nylon 14 2
* 744039 . . Cable-tie 1 -
* 424245 . Strap 1 -
* 710492 . Screw, csk hd, M3 x 10 1 -
* 490292 . Ribbon cable 1 -
* 425144 . Earth wire 1 -
* 695777 . Cable tie 2 -
* 380072 . Ferrite clamp 1 -
28 424164 424182 . Band heater 1 -
29 424259 . Cover, band heater 1 -
* 307046 . . Nut, 4BA 1 -
* Not shown ** was T2A, T3.15A now prefered Continued
To Next Page
