Press if the feeler position is correct.
Press to loosen the clamps and remove the plastic pattern, then to return to the work screen.
Press if the feeler position is not correct.
b. Calibrating the touch screen
Calibrate the touch screen if your operations have become difficult due to lack of precision.
Touch screen malfunction
You can directly access the calibration screen without using the settings menu. To do this, press on the edging screen for 5
seconds.
Calibrating the touch screen
Select > > from the work screen.
Press to start calibration.
Press to cancel and return to the menu
Point precisely on each cross as they are displayed, holding the stylus perpendicular to the screen so as not to alter the
calibration.
Press to return to the work screen.
5. Statistics and technical history of the tracer
This menu enables you to visualize the number of cycles carried out by the tracer-centerer-blocker. It also gives you access to the
technical history.
Tracer-centerer-blocker statistics (p.129)
Technical history and errors (p.132)
a. Tracer-centerer-blocker statistics
From the work screen, select > > > to visualize the number of cycles performed by the tracer-centerer-blocker.
There are three states of statistics:
statistics of the edger alone
statistics if the Tess tracer is connected
statistics if the Tess tracer is connected but not turned on
The calibration cycle is complete.>
A message is displayed indicating that calibration by a technician is required: contact your technical department.>
A confirmation message is displayed:>
The settings menu is displayed automatically once the calibration is finished.>
