USER MANUAL > CENTER AND BLOCK A LENS
40
Delta 2 - Edging system > v2 - 08.16
1.
2.
3.
4.
Centering screen
Active eye and type of display of PD and pupillary height
Information on the right eye
Visual cue of the frame positioned facing the screen
Information on the left eye
It is possible to start independently with the right eye or the left eye. On the other hand, the change of the eye must be carried
out manually.
