1. Introduction
Technical data
Turn the tracer on using the on/off switch.
Complies with ISO16284 Standard (VCA compatible).
Automatic autotest when turned on.
Calibration, in connection with the micro-computer (PC) or from the tracer.
Cycle counter available on the software installed on the computer.
Automatic insertion of the feeler
Tracing in 3 dimensions for frames, 2 dimensions for patterns, demo lenses or already cut lenses.
The “remote lens edging” precision will be assured only on closed frames.
High-Precision Tracing with profile reading of the frame groove.
Support provided for the tracing of a pattern or a lens (demo or already cut).
Automatic measurement of the bridge of the frame, in binocular tracing.
Frame thickness measurement.
Differential tightening of the clamps.
RS232 port and RJ-45.
Update of the memories via Essilor external USB key .
Built-in memory: 200 Jobs.
Digital display 2 X 16 characters.
Integrated functions of auto-maintenance, from the micro-computer (PC), or from the Delta T edger.
Power supply: 12V
External power: 100-240 VAC, 1 A, 50-60 Hz, Output 12 V.
Limits of frame dimensions:
B-dimension 17mm minimum (pattern: 18.5mm), 58mm maximum.
A-dimension 28mm minimum, 70mm maximum.
Z Height limit: 30mm in binocular, 40mm in monocular.
Frame thickness : 1.45mm minimum, 12mm maximum.
Dimensions: (L) 280mm X (D) 285mm X (H) 180mm.
Weight: 7.5kg
Due to constant improvements, these specifications may be modified without prior notice.
