MENU SETUP 1/2
MENU MODE EXPERT
METER TYPE pH
T SENSOR NONE
SET TEMPERATURE 25.0
CALIBRATION MENU TIMEOUT 05:00
DELAY AT STARTUP 00:05
AUX OUTPUT MODE OFF
YEAR 2013
MONTH 5
DAY 15
7.4.7. AUX OUTPUT MODE
The controller has a calendar and an internal clock for the management of the exits with timer and the storage of
the data recorded by the controller; in order to set up the clock the following settings must be carried out.
Once the date and time are set, by pressing the + or - key, the choice are the follow:
 OFF function: the aux output is deactivated;
 Cleaning function: it is possible to activate a dosing pump for the cleaning of the electrode, up to a
maximum of 4 interventions (timer and scheduled mode) during the day; the difference from the
flocculant mode, is that the Cleaning mode interrupts the tool’s operations (disabling the set-point). At
the end of such intervention the tool awaits the start up time (see DELAY AT STARTUP).
 Flocculant function: it is possible to activate the flocculant dosing system, up to a maximum of 4
interventions (timer and scheduled mode) during the day.
Starting from the MENU SETUP screen, enter in AUX OUTPUT MODE by pressing + key or – key.
After selected AUX OUTPUT MODE press OK key to set between OFF, CLEANING and FLOCCULANT.
Once one of the two functions is activated (flocculant or cleaning) it is necessary to set the auxiliary outputs
that need to be activated by select the days in which the auxiliary output needs to be activated.
7.4.7.1. CLEANING AUX OUTPUT MODE
Starting from the MENU SETUP screen, and selected CLEANING as AUX OUTPUT MODE press OK key.
Than Set CYCLE TIME, WEEKDAYS1, WEEKDAYS2, WEEKDAYS3, WEEKDAYS4 as follow:
 CYCLE TIME: define how long time the AUX OUTPUT relay have to be activated;
 WEEKDAYS1, WEEKDAYS2, WEEKDAYS3, WEEKDAYS4 : define the days of the week in wich the
aux output have to be activated; after setting the WEEKDAYS on the display appear to set the START
TIME
7.4.7.2. FLOCCULANT AUX OUTPUT MODE
Starting from the MENU SETUP screen, and selected FLOCCULANT as AUX OUTPUT MODE press OK
key.
Than Set CYCLE TIME, WEEKDAYS1, WEEKDAYS2, WEEKDAYS3, WEEKDAYS4 as follow:
 CYCLE TIME: define how long time the AUX OUTPUT relay have to be activated;
 WEEKDAYS1, WEEKDAYS2, WEEKDAYS3, WEEKDAYS4 : define the days of the week in wich the
aux output have to be activated; after setting the WEEKDAYS on the display appear to set the START
TIME
Press + or – to choose between OFF,
CLEANING and
FLOCCULANT.
