MENU SETPOINT1 2/2
METER READING @20mA 14.00
7.5.1. SETPOINT
After setting up the instrument, the SETPOINT values must be set: the instrument features two independent
SETPOINTS ( SETPOINT1 and SETPOINT2 ) actuating two relating relay outputs.
On the previous screen is show how set the values for these setpoints. After set the SETPOINT parameter,
press OK key to move the cursor on right column and set the value by press + or – keys.
After set the setpoint value press OK key to confirm.
7.5.2. MODE
Defining the type of actuation: ACID or ALKALINE in the case of pH, DOWN and UP in the case of REDOX and
CL; they represents the action tends to decrease or increase the measurement.
After set the MODE parameter, press OK key to move the cursor on right column and set the value by press +
or – keys.
Press OK key to confirm the setted value.
7.5.3. HYSTERESIS
After defining the type of actuation, setting the hysteresis value is the next step.
After set the HYSTERESIS parameter, press OK key to move the cursor on right column and set the value by
press + or – keys.
Press OK key to confirm the setted HYSTERESIS value.
7.5.4. SETPOINT DELAY
The instrument allows the user to define a delay time relating to SETPOINT actuation.
After set the SETPOINT DELAY parameter, press OK key to move the cursor on right column and set the value
by press + or – keys. Use the ►key to move from minutes to seconds. Press OK key to confirm the setted
SETPOINT DELAY time.
