2
Parameter Value
Input Voltage
90-240 Vac 50/60Hz, 12-24 Vdc, 24Vac
Power Consumption
15 W (1 A peak current)
Operating temperature range 0 – 40°C
SETPOINT relay output
terminals max current
16 ampere with resistive load
3 ampere with inductive load
2 setpoints
Auxiliary relay output
terminals max current
5 ampere with resistive load
0.7 ampere with inductive load
1 auxiliary output
Alarm relay output
terminals max current
5 ampere with resistive load
0.7 ampere with inductive load
1 alarm output
Current output 4 - 20 mA (dynamic 0..500 Ω) 2 current outputs
TTL output 0 – 999 pulse/min 2 open collector TTL outputs
pH range 0 … 14 0.01 pH resolution
Rx range (mV)
-1000 ….+1400 ± 1 mV Rx resolution
Chlorine range
0÷2; 0÷20; 0÷200; 0÷2000 ppm
0,001/0,01/0,1/1 ppm
Temperature range
0 – 100°C 0.1°C
Level control – PT100 connection – Relay output 6A (resistive load) 1A (inductive load)
1. GENERAL INFORMATIONS
Electronic instruments controlling electrochemical parameters such as pH, Redox or Chlorine are
widely used in swimming pools, waterworks and water treatment plants.
The eSelect Series Controllers stand out for the following features:
Capability of performing the most possible measurements with just one type of electronic
board: pH, Redox (mV), Cl (ppm).
Simple and easy to learn programming procedure providing two types of menu: a SIMPLE
menu allowing the user to control indispensable functions, and a EXPERT menu giving the
user the full capability of setting all functions.
Galvanically isolated electronics providing a high level of immunity to disturbances.
2. TECHNICAL DATA
