8 LPC operation
Autocontrols
The front panel buttons, M1–M7 have programmable as well as fixed
functions. Each can operate a macro in your show, as explained under
Macro control, page 7. They may also be used in combinations to give you
access to software displays and to make settings.
When panel buttons, including the Read From Disk button, are used in
non-programmable combinations, they are called autocontrols. Execute an
autocontrol using the following 4-step procedure.
1. Press M7 and hold.
2. Press the additional button or buttons and hold.
3. Release M7.
4. Release the additional button or buttons.
An Express LPC with version 3.1 system software contains the following
autocontrols.
Autocontrol buttons Function
M7 / M1 Stage display
M7 / (M1 and M2) Plus
M7 / M3 Patch display
M7 / (M1 and M3) Enter
M7 / (M2 and M3) Minus
M7 / (M1 and M2 and M3) Clear
M7 / M4 Setup display
M7 / (M1 and M5) Reboot
M7 / (M5 and M6) Nothing
a
a) Use this autocontrol to back out of an autocontrol
operation without changing anything.
M7 / (M1 and M6) Softkey [S1]
b
b) The softkeys apply to the existing display, as viewed
on your video monitor.
M7 / (M2 and M6) Softkey [S2]
M7 / (M3 and M6) Softkey [S3]
M7 / (M4 and M6) Softkey [S4]
M7 / (M1 and M5 and M6) Softkey [S5]
M7 / (M2 and M5 and M6) Softkey [S6]
M7 / (M3 and M5 and M6) Softkey [S7]
M7 / (M4 and M5 and M6) Softkey [S8]
M7 / (M1 and M2 and M3 and
M4 and M5 and M6)
Record
M7 / Read From Disk
Read system
configuration
