Euphonix System 5 Installation Guide Interconnecting System Components

Console Dimensions

Figure 2-3 Console Dimensions - Top

Figure 2-4 Console Dimensions - Side

41.0

72.0 4.04.0

30.5

39.5

29.5

24.2
