Euphonix System
5 Installation Guid
e
Inter
c
onnectin
g
System
Compon
ents
27
Suggested Rack Elevations
Figure 2-8
Single and
Redundant-core Systems
Leave Open
EuCon Switch
System PC
DF66 SuperCore 1
CO600 Changeover Switch
DF66 SuperCore 1A
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Leave Open
Eucon Switch
12
System PC
DF66 SuperCore
0
1
2
3
4
5
6
7
8
9
10
11
Leave Open
Leave Open
26
28
Table of Contents
Default Chapter
1
Installation Guide
1
Table of Contents
3
List of Figures
5
Chapter 1: System 5 Overview
9
Theory of Operation
9
Digital Signal Processing (DSP)
9
Control Surface
10
System Configuration
11
DAW Control
11
I/O
11
Monitoring
13
Snmp
13
Power
14
Sync
14
System Control Connections
15
Estimating System Requirements
16
Number of DF66 DSP Line Cards
16
DF66 Requirements
16
Number of CM408T Eight-Channel Sections
17
I/O Specification
17
Summary of Euphonix "Classic" Converters and Interfaces
17
Summary of Euphonix Modular I/O
17
Summary of System 5 Components
18
Chapter 2: Interconnecting System Components
19
Component Specifications
19
System 5 Components: Dimensions, Power Consumption, Heat Dissipation
19
Facility Power Quality Recommendations
21
Typical Room and Equipment Layout for System 5
23
Typical Console Layout
23
System 5 Console
23
Console Dimensions
24
Console Dimensions - Top
24
Console Dimensions - Side
24
S5MC Console Dimensions - Top
25
S5MC Console Dimensions - Side
25
Suggested Rack Elevations
27
Single and Redundant-Core Systems
27
Audio Hookup
28
Audio Hookup for Modular I/O
29
Synchronization Hookup
30
Recommended Sync Distribution Method
31
MADI Hookup
33
Control Hookup
35
Chapter 3: System 5 Components
36
DF66 Supercore
36
SP662, 6X6 Bridge, and Sync Cards
37
Sync Card
38
Bridge Card
38
SP662 DSP Line Card
38
MADI I/O DSP Line Card Cable
38
System 5 Console
39
Port BNC Bulkhead Panel
39
Typical Talkback Wiring
40
Switch Functions
40
SC263 System Computer (S5B Only)
41
SC263 Front and Rear Panels
41
SC264 System Computer
43
SC264 Front and Rear Panels
43
MC524 Monitor Interface
45
MC524 Front and Rear Panels
45
Input/Output Connections
46
Elco 38 Connector
46
In 1 Elco 38 Pinout
46
Elco 90 Connector
47
In 2 Elco 90 Pinout
47
Elco 90 Connector
48
Out 1 Elco 90 Pinout
48
Elco 90 Connector
49
Out 2 Elco 90 Pinout
49
DB-25 Connector
50
Out 3 DB-25 Pinout
50
ML530 MIC/Line Interface
51
ML530 Front and Rear Panels
51
ML530 in 1/In 2 Pinout: Elco 38 Socket
52
ML530 out 1/Out 2 Pinout: Elco 38 Socket
52
CO600 Changeover Switch
53
AM713 Analog to MADI Converter
54
Front Panel
54
AM713 Front Panel
54
Rear Panel
55
AM713 Rear Panel
55
MA703 MADI to Analog Converter
57
Front Panel
57
MA703 Front Panel
57
Rear Panel
58
MA703 Rear Panel
58
DM714 AES/EBU to MADI Converter
60
Front Panel
60
DM714 Front Panel
60
Rear Panel
61
DM714 Rear Panel
61
DM714 Parallel AES/EBU Digital Inputs: Female DB-25
62
MD704 MADI to AES/EBU Converter
63
Front Panel
63
MD704 Front Panel
63
Rear Panel
64
MD704 Rear Panel
64
DM704 Parallel AES/EBU Digital Outputs: Female DB-25
65
FC726 Format Converter
66
FC726 Front and Rear Panels
66
AES/EBU DB-25 Pinout
68
Common DD-50 Connector Pinout and Usage with Third-Party Devices
69
FC726 TDIF Cable Wiring Specification
70
FC726 SDIF Cable Wiring Specification
71
Modular I/O
72
Modular I/O Modules
73
More Modular I/O Modules
75
AD914 RJ-45 Pinout
76
Stagebox Configuration #1
77
Local-Side Interface Configuration #1
77
I/O Module Summary
78
Control Module Summary
78
Frame Summary
78
Tt002
79
Input and Output Connections
79
TT002 Card and Panels
79
TT002 P1 Connections and Pinouts
79
Connector Pinouts (DC-37 1 and 2)
80
Simplified TT002 GPO and GPI Circuits
81
FT730 Fibertran Fiberoptic Extender
82
FT730 Front Panel
82
FT730 Front Panel Status Leds
82
FT730 Rear Panel
83
Internal Sync Input Jumper
84
Rear Panel TCC, MADI, and Fiber Connectors
85
