ISIS user manual
Issue G
128
IDE drive support Primary IDE Controller onboard ICH4.
Supports Ultra ATA100/66/33, PIO and 8237 style DMA
transfers.
40-way 2.54mm IDE connector support provided.
Floppy drive support 100% IBM compatible 2.88MB floppy drive controller with
integrated digital separator and dual floppy drive support
I/O ports One IEEE1284 parallel port (ECP, EPP and SPP modes).
One PS/2 mouse port.
One PS/2 keyboard port.
Four serial ports (3 x RS232, 1 x RS485/RS422/RS232
selectable).
One IrDA infrared port (Uses a UART port).
One LCD backlight connector.
Two user jumpers.
One front panel connector providing LCD character display
support, 2 x user LEDs, SMBUS interface and 2 x GPIO.
One CD ROM audio input connector.
One Interface connector to optical S/PDIF transceiver.
Network support Dual 10/100 Ethernet support.
Factory build option of Gigabit Ethernet on primary LAN
interface.
WOL, WfM, PXE and ASF 1.03 provided on primary LAN
interface.
All Ethernet controllers interface to board mounted RJ-45’s
Real time clock Motorola MC146818B-compatible real-time clock with
256bytes of battery backed SRAM, integrated in ICH4.
A tamper detection circuit is also included in the RTC
circuit and it’s status held in RTC SRAM memory.
Power consumption 36W at 1.6GHz (full speed).
12.3W at 600MHz (at idle).
(Based on a Pentium M 1.6GHz CPU with 512MB PC2700
DDR memory and SpeedStep disabled, i.e. running at
fixed frequency.)
CompactFlash
®
Single 50 pin CF+ version 2.0 Type I/II socket for full IO
mode operation.
IEEE1394a Two IEEE1394a-2000 Firewire compliant ports
100/200/400 Mbps.
USB Six USB 2.0 compliant ports capable of high-speed, full-
speed and low-speed operation
BIOS 8Mbit Firmware Hub (FWH). CMOS settings battery
backed.
