Appendix A – Specification
Issue G 129
Temperature Fan-less operation (passive cooling): -20°C to +65°C
(based on Pentium M CPU running at 600MHz).
Operating (active cooling): -20°C to +65°C (based on
Pentium M CPU running at 1.6GHz).
Storage -40°C (-40°F) to +70°C (158°F).
Humidity 10% to 90% RH (non-condensing).
Real-time clock Accuracy +/- 1min/month at 25
o
C (77
o
F).
Power requirements ATX Compatible power supply.
Typical supply rail requirements with Pentium M 1.6GHz.
12V +/- 5% 2.5A (typical), 3A (max).
5V +/- 5% 1.0A (typical), 1.5A (max).
5V Standby +/- 5% 0.5A (typical), 1A (max).
3.3V +/- 5% 1.0A (typical), 1.5A (max).
Battery 3.0V Lithium 180mAH (CR2032 Coin Cell).
Maximum discharge current 6uA.
Dimensions EBX-compatible format
5.75" x 8.00", 146mm x 203mm
Weight 350 grams (with no heatsink, processor or memory).
