Page 17/84
December 2019W11/W12/W13 | Operation manual
3.1.3 Adjusting the driver's seat
Accident hazard due to distraction! Do not adjust the driver's seat while driving, only when the wheel loader is at a
standstill!
You can adjust the driver's seat according to your individual height and posture requirements. This prevents tension
and fatigue during work.
Adjust the seat so that you can comfortably reach the lever and pedals while your back is against the backrest.
The following seat settings are possible:
1. Fore/aft adjustment: Pull the locking lever to adjust the seat fore and aft position. After adjustment the locking
lever must lock into the required position. After locking, the driver's seat should no longer move.
2. Backrest adjustment: Pull the locking lever to adjust the backrest. Now slide the seat forwards or backwards
until the desired backrest angle is achieved. The locking lever must lock into the required position.
After locking, the backrest should no longer move.
3.1.4 Steering column adjustment (optional extra)
Accident hazard due to distraction! Do not adjust the driver's seat while driving, only when the wheel loader is at a
standstill!
You can adjust the longitudinal position of the steering column and
thereby adapt it to your individual height and posture requirements.
1. Loosen the adjusting lever by rotating.
2. Adjust the steering column to your needs.
3. Firmly tighten the adjusting lever.
3.1.5 Safety belt
Risk of injury! Always wear the safety belt when working! Do not apply the safety belt over the top of solid or fragile
objects (e.g. glasses, keyring)! Inspect the belt and the buckle before use! Replace the belt and the buckle
immediately if damaged!
