Page 56/84
December 2019W11/W12/W13 | Operation manual
10.5 General safety checks
Rectify any damage identified during the safety check immediately. Damaged parts must be repaired or replaced
immediately!
The wheel loader may only be used after the damage has been professionally repaired!
Check:
• All steel parts for damage and loosened screw connections, especially the protective structure;
• The condition of the seatbelt;
• The quick-change system for the attachments;
• That all pivot pins are in the correct position and secured by their locking device;
• That running board and hand-holds are OK and fit correctly;
• Cabin glass for breaks and cracks;
• The condition of the rear light and lighting, including the work spotlight;
• The tires for damage and penetrating sharp objects;
• The condition of all warning and instruction decals!
10.6 Specifications and fill volumes
Note When filling with oil, filling to the markings on the dipsticks or the inspection screws is mandatory.
Engine
MODEL Capacity Specification
D1105-E3B/D1105-T-E3B 5.1 L 15W-40 API CF-4/SG to D2
V1505-E3B/V1505-T-E3B 6.7 L 15W-40 API CF-4/SG to D2
V 2403-M-DI-E3B 9.5 L 15W-40 API CF-4/SG to D2
Cooling
TYPE SPECIFICATION ANTI-FREEZE -35 °
W11 11 L
W12 13 L
W13 15 L
Hydraulics
TYPE SPECIFICATION CALTEX HDZ-46
W11 66 L
W12 50 L
W13 80 L
