Page 31/84
December 2019W11/W12/W13 | Operation manual
1. Lower the attachment.
2. Unit with hydraulic function:
- Switch off the engine.
- Switch on the ignition.
- Press the ancillary hydraulics button and move the joystick
several times in both directions. This depressurizes the
ancillary hydraulics lines.
3. Pull the quick-release couplings apart.
4. Attach the protective caps.
5. Place the hydraulic hoses over the attachment.
6. Retract the locking bolt using the quick-change device lever.
7. Lower the lifting frame and tip it away from the attachment. This
releases the locating bolts from the locating hook.
8. Reverse the wheel loader away when the locating hooks are
released.
3.4.7 Front bucket
The lightweight goods bucket is used with light materials, such as cereals, corn and concentrates.
The soil bucket is used for heavy materials, e.g. gravel, sand, soil and rock.
Avoid overloading! Observe the max. permissible operating load.
Operate the control lever carefully!
