10.9 Decommissioning and recommissioning the wheel loader
The specified measures refer to decommissioning and recommissioning the wheel loader for extended periods.
Observe the engine operating instructions!
Decommissioning the wheel loader
• Park the wheel loader as described in section 10. "SERVICING AND INSPECTION".
• Block the articulated joint.
• Jack up such that the tires no longer touch the ground.
• Release the parking brake.
• Lower the lifting frame completely.
• Carry out the "Discharging residual pressure in hydraulic system" and put the control lever in the 0 position.
• Spray bare metal parts of the wheel loader (e.g.: the piston rods of the hydraulic rams, if they are not retracted)
with anticorrosive agent.
• Preserve the engine.
Preserve the engine
• Clean the engine using a high-pressure cleaner at a suitable location.
• Bring the engine to operating temperature.
• Drain the engine oil and dispose of it in an environmentally compatible manner.
• Fill the engine with anticorrosive oil.
• Drain the fuel tank.
• Produce a mixture of 90% fuel and 10% anticorrosive oil and top up the fuel tank.
• Allow the engine to idle for 10 minutes, then turn it off.
• Turn over the engine several times by hand to aid cylinder and combustion chamber preservation.
• Remove the fan belt and place it in airtight and light-tight storage.
• Spray the running surfaces of the pulleys with anticorrosive agent.
• Seal off the engine intake and exhaust ports.
Battery storage
• Remove the battery.
• Clean the battery.
• Charge the battery.
• Store the battery in a dry and well ventilated room at approx. 20 °C.
• Check the battery acid level monthly.
• Recharge the battery before reuse.
