Page 57/84
December 2019W11/W12/W13 | Operation manual
Only perform servicing and inspection work if the wheel loader is secured as described in section 10. "SERVICING
AND INSPECTION"!
In order to better carry out servicing and inspection work, it is possible to tip the driver's seat forwards.
10.7 Servicing
10.7.1 Tipping the driver's seat
Remove all tools and objects from the engine and from the engine compartment before tilting the driver's seat.
Risk of injury due to moving parts! Do not tilt the driver's seat while the engine is running.
Risk of injury due to unintentional tipping of the driver's seat!
If necessary, the driver's seat must be pushed forward slightly on the forward/backward adjustment.
Axis
TYPE SPECIFICATION GL85W90 GEAR OIL
W11 2 L
W12 7.5 L
W13 12 L
Fuel tank
TYPE SPECIFICATION Diesel fuel
W11 26 L
W12 42 L
W13 60 L
