Page 38/84
December 2019W11/W12/W13 | Operation manual
4.2 Transporting
Only load and transport the wheel loader if all safety regulations are met!
Only trained personnel may load and transport the wheel loader. The carrier always bears the responsibility for
loading and transporting!
Blocking the articulated joint
Always block the articulated joint before the wheel loader is lashed to transportation equipment!
Do not move the steering with the articulated joint blocked. After transportation, first remove the jackknife guard!
The jackknife guard is attached to the front of the vehicle with bolts and secured with cotter pins.
1. Drive the wheel loader until it is straight.
2. Remove the cotter pins.
3. Reposition the jackknife guard.
4. Secure the jackknife guard using the cotter pins.
Release the blocking in reverse order.
