December 2019W11/W12/W13 | Operation manual
Dimensions
Number W11 W12 W13
A 3660 4620 5100
B 2890 3600 3890
C 425 704 740
D 1375 1600 1860
E 950 1083 1230
F 2175 2225 2270
H 1118 1249 1250
J 3370 3728 3780
I 2930 3100 3230
L Bucket 2700 2810 2930
L Pallet forks 2800 2890 3000
M 2130 2177 2480
N 525 517 540
O606565
P Industrial tires / 1120 1140 or 1340 (reversible rims)
P Wide tires 1103 1400 1600
Q 763 802 1040
R 820 1010 1140
S90225410
T 2040 3085 2635
U 2125 2597 2320 (industrial tires: 1140)
V 1110 1450 1200
W 45° 45° 45°
X 55° 45° 45°
Y 43° 43° 43°
