December 2019W11/W12/W13 | Operation manual
Hydraulic oil replacement
Scalding hazard due to hot hydraulic oil!
Use a sufficiently dimensioned drip tray to collect the old hydraulic oil and use the correct oil (see 10.6
"Specifications and fill volumes".)
1. Park the loader on a horizontal surface and apply the parking brake.
2. Lower the lifting frame completely.
3. Switch off the engine.
4. Depressurize the hydraulic system.
5. Place a sufficiently dimensioned drip tray beneath the hydraulic tank drain plug.
6. Unscrew the plug.
When the hydraulic oil has drained
1. Remove the filter element.
2. Clean the tank bottom and inside of the tank with hydraulic or flushing oil through the opening.
3. Replace the return filter element.
4. Refit the plug.
5. Fill hydraulic oil into the hydraulic oil filler neck until the oil level reaches the "Maximum" mark.
6. Close the hydraulic oil filler neck.
7. Bleed the hydraulic system.
8. Check the hydraulic oil level and top up if necessary.
9. Dispose of the old hydraulic oil in an environmentally compatible manner.
Replace the hydraulic filter element
Replace the filter element during the inspections.
ENVIRONMENTAL INFORMATION
Allow the pressure in the hydraulic oil tank to dissipate by opening the hydraulic oil filler neck before unscrewing
the filter casing cover. Otherwise oil is forced out of the filter casing and may enter the environment. Dispose of the
old filter element and escaped hydraulic oil in an environmentally compatible manner.
1. Park the loader on a horizontal surface and apply the parking brake.
2. Lower the lifting frame completely.
3. Switch off the engine.
4. Depressurize the hydraulic system.
5. Unscrew the filter casing cover.
6. Remove the filter element.
7. Fit a new filter element.
8. Check the seal. Replace the seal.
