December 2019W11/W12/W13 | Operation manual
Connecting and disconnecting the battery/battery replacement
Risk of injury due to moving parts!
Never open the hood with the engine running! Always disconnect the battery in the correct sequence!
• Disconnecting: First the negative terminal and then the positive terminal!
• Connecting: First the positive terminal and then the negative terminal!
Removing the battery
1. Park the loader on a horizontal surface and apply the parking brake.
2. Lower the lifting frame completely.
3. Switch off the engine.
4. Before disconnecting the battery, switch off all electrical loads (and the battery isolator switch) and remove the
ignition key.
5. Unscrew the towing equipment ring nuts.
6. Open the rear panel.
7. Unscrew the cable from the negative terminal.
8. Unscrew the cable from the positive terminal.
9. Unscrew the battery holder.
10. Take the battery by its handles and lift it out.
The battery is installed in reverse order.
