c-pro 3 OEM - Hardware manual
Technical data
Type Description
Purpose of the control device Function controller
Construction of the control device Built-in electronic device
Container Grey, self-extinguishing
Category of heat and re resistance D
Dimensions Open frame version – 142 x 110 x 31 mm
(5
9
⁄16 x 4
5
⁄16 x 1
1
⁄4 in)
Plastic housing version – 142 x 128 x 60 mm
(5
9
⁄16 x 5
1
⁄16 x 2
3
⁄8 in)
Mounting methods for the control device To be tted on a DIN rail, in a control panel
Degree of protection provided by the covering Open frame version IP00
Plastic housing version IP20
Connection method Open frame version – Screw terminal blocks for wires up
to 2.5 mm²
– Type A female USB connector.
Plastic housing version – Removable screw terminal blocks
for wires up to 2.5 mm²
– Type A female USB connector.
Maximum permitted length for connection cables Power supply: 10 m (32.8 ft)
Analogue inputs: 10 m (32.8 ft)
Auxiliary power supply and 0-5 V ratiometric transducer power supply:
10 m (32.8 ft)
Digital inputs: 10 m (32.8 ft)
0-10 V analogue outputs: 10 m (32.8 ft)
PWM analogue outputs: 1 m (3.28 ft)
Digital outputs: 100 m (328 ft)
INTRABUS port: 10 m (32.8 ft)
RS-485 MODBUS port: 1.000 m (3.280 ft)
USB port: 1 m (3.28 ft)
CAN port:
– 1.000 m (3.280 ft), baud rate: 20.000 baud
– 500 m (1.640 ft), baud rate: 50.000 baud
– 250 m (820 ft), baud rate: 125.000 baud
– 50 m (164 ft), baud rate: 500.000 baud
Operating temperature Open frame version -20 – 60 °C (-4 – 140 °F)
Plastic housing version - blind -20 – 55 °C ( -4 – 131 °F)
Plastic housing version - LCD -10 – 55 °C (14 – 131 °F)
Storage temperature Open frame version -20 – 70 °C (-4 – 158 °F)
Plastic housing version - LCD -20 – 70 °C (-4 – 158 °F)
Plastic housing version - blind -20 – 70 °C (-4 – 158 °F)
Operating humidity Relative humidity without condensate from 5 to 95%
Pollution status of the control device 2
Compliance – RoHS 2011/65/CE
– WEEE 2012/19/EU
– REACH (EC) Regulation no. 1907/2006
– EMC 2014/30/UE
– LVD 2014/35/UE
Power supply 115... 230 VAC (+10% -15%)
50/60 Hz (±3 Hz)
max. 10 VA
Earthing methods for the control device None
