Evco c-pro 3 Series User Manual

EVCO S.p.A. c-pro 3 | Hardware manual ver. 2.0 | Code 114CP3E204
page 34 of 86
The maximum length of the connecting cables of the PWM analog output is 1 m (3.280 ft); the one of the connecting cables of
the 0-20 mA / 4-20 mA / 0-10 V analog outputs is instead of 30 m (98 ft).
For the settings about the analog outputs look at chapter 6 “CONFIGURATION”.
The analog output 1 is usable on condition that the expansion is powered in alternate current and the phase powering the controller is
the same powering the user driven by the output.
ANALOG INPUTS/OUTPUTS (in c-pro 3 EXP hecto+ only)
Analog inputs and analog outputs.
Terminal Meaning
AI4 analog input 4 (NTC probes)
AO1 analog output 1 (PWM signal)
GND ground
AO2 analog output 2 (configurable via configuration parameter for 0-20 mA / 4-20 mA / 0-10 V signal)
AO3 analog output 3 (configurable via configuration parameter for 0-20 mA / 4-20 mA / 0-10 V signal)
The maximum length of the connecting cables of the PWM analog output is 1 m (3.280 ft); the one of the connecting cables of
the 0-20 mA / 4-20 mA / 0-10 V analog outputs is instead of 30 m (98 ft).
For the settings about the analog outputs look at chapter 6 “CONFIGURATION”.
The analog output 1 is usable on condition that the expansion is powered in alternate current and the phase powering the controller is
the same powering the user driven by the output.
The analog output 1 and the analog output 2 are not independent each other but they work in the same way.
DIGITAL INPUTS
Free of voltage digital inputs.
Terminal Meaning
COM common digital inputs
DI1 digital input 1
DI2 digital input 2
DI3 digital input 3
DI4 digital input 4
DI5 digital input 5
The maximum length of the connecting cables of the digital inputs is 100 m (328 ft).
