EVCO S.p.A. c-pro 3 | Hardware manual ver. 2.0 | Code 114CP3E204
page 76 of 86
The maximum lengths of the connecting cables are the followings:
• power supply controller: 30 m (98 ft)
• analog inputs: 100 m (328 ft)
• power supply transducers: 100 m (328 ft)
• digital inputs: 100 m (328 ft)
• PWM analog output: 1 m (3.280 ft)
• 0-20 mA / 4-20 mA / 0-10 V analog outputs: 30 m (98 ft)
• digital outputs (electromechanical relays): 100 m (328 ft)
• RS-485 ports: 1,000 m (3,280 ft); also look at the Manuale Modbus specifications
and implementation guides
• CAN port:
- 1,000 m (3,280 ft) with baud rate 20,000 baud
- 500 m (1,640 ft) with baud rate 50,000 baud
- 250 m (820 ft) with baud rate 125,000 baud
- 50 m (164 ft) with baud rate 500,000 baud
• power supply user interface: 30 m (98 ft).
One suggests using the
connecting kit CJAV15
(female extractable screw
terminal blocks pitch
5.0 mm, 0.196 in; to order
separately).
One suggests using the
connecting kit CJAV16
(female extractable screw
terminal blocks pitch
5.0 mm, 0.196 in; to order
separately).
To program the controller one has to use the programming
kit EVIF20TUXI (TTL / USB isolated serial interface + TTL
cable 2.5 m, 8 ft long + USB cable 2 m, 6 ft long; to order
separately).
One suggests using the
connecting kit CJAV15
(female extractable screw
terminal blocks pitch
5.0 mm, 0.196 in; to order
separately).
Working temperature:
from -10 to 55 °C (14 to 131 °F) for the built-in versions, from -20 to 55 °C (-4 to 131 °F) for
the blind versions.
Storage temperature:
from -30 to 70 °C (-22 to 158 °F).
Working humidity:
from 5 to 95% of relative humidity without condensate.
Pollution situation:
2.
Working altitude:
from 0 to 2,000 m (0 to 6591 ft).
Transport altitude:
from 0 to 3,048 m (0 to 10,000 ft).
Ambient conformity:
ROHS 2002 / 95, WEEE 2002 / 96 / EC, REACH CE 1907 / 2006.
EMC conformity:
EN / IEC 60730-1 enclosure 16.
