Everbilt EFLS15CI-HD - Care and Cleaning; Clearing a Clogged Pump

9
HOMEDEPOT.COM
Please contact 1-844-883-1872 for further assistance.
Care and Cleaning
To clear a pump clogged wit
h debris:
1. Unplug the pump from electrical power.
2. Remove four screws (8).
3. Remove the volute (2), O-ring (2), and O-ring (3).
4. Remove three screws (4) fastening the diffuser (5) to the seal plate (7) and remove the diffuser (5).
5. Remove debris from around the impeller (6).
6. Reassemble the pump.
11 3 5 642
7
8
