100
Ventilation System
Opening Windshield in the Open Position
Windshield UP/DOWN Switch in Hardtop Switch Panel
Opening Windshield in the Closed Position
10.2 Windshield/Helm
Compartment Ventilation
The windshield can be lowered to provide ven-
tilation at the helm and improved visibility. The
windshield is raised and lowered by hydraulic
cylinders activated by an electric hydraulic pump
in the cabin bilge below the berth. The system
is controlled by the UP/DN switch in the hardtop
switch panel.
To lower the windshield, press and hold the switch
in the down position until the windshield is lowered
to the desired position, then release the switch.
To close the windshield, hold the switch in the up
position until the windshield is completely closed.
Always release the switch immediately when wind-
shield reaches the full down or full up position.
A limit switch in the slide track prevents the wind-
shield wiper from operating while the windshield
is lowered. Always make sure the windshield is
in the full up position before attempting to use
the wiper.
