Topaz Router
Page 20 Revision 2.0
4.2.7. Power Specs
Supply, external: Auto ranging 100 to 240V AC 50/60Hz
Power Consumption: 20W
Connections: Two pin bayonet locking
Power Fail Alarm Output: Relay contact rated 250mA, 50V
Connector screw terminals
Redundant PSU: Optional
4.2.8. Physical Specs
Height: 3.5” (90mm)
Width: 19” (483mm)
Depth: 4.75” (120mm)
Weight:
Frame: 1.45kg
PSU: 0.4kg
Operating Temp. (ambient): 0-40°C
Specification Maintained (ambient): 10-30°C
Humidity: 10-90% non-condensing
Ventilation: Natural convection
