Evolis Pebble Quick Operating Guide

The Pebble printer is fitted with a manual adjustment system for the
thickness of the cards that is accessible either from inside the printer
or when the cover is open.
To adjust the thickness of the cards using the feeder cage:
To adjust the card thickness from inside the printer:
10
Remove the feeder
from the printer as
shown.
Adjust the thickness of the
cards used by moving the
handle from right to left on
the required card thickness.
Card thickness adjustment
Replace the feeder in
the printer Then press
on the top of the feeder
until it clicks.
max.
Open the printer
cover by pressing the
opening lever and
then turn it.
Remove the ribbon if there is one
in the printer. Then adjust the
thickness of the cards used by
moving the handle from right to
left on the required card thickness.
Reinstall the ribbon in
the printer and close
the cover.
CLIC
Cards loading

Evolis Pebble Specifications

General

Resolution	300 dpi
Memory	16 MB RAM
Printing Technology	Dye-sublimation
Print Speed	Color: 150 cards/hour (YMCKO), Monochrome: 1000 cards/hour
Card Types	PVC, Composite PVC
Card Thickness	0.76 mm
Interface	USB 2.0
Encoding Options	Magnetic stripe
Card Input Capacity	100 cards (0.76 mm)
Card Output Capacity	50 cards (0.76 mm)
Card Dimensions	ISO CR80 - ISO 7810 (53.98 mm x 85.60 mm)
Operating System Compatibility	Windows XP, Vista, 7
Power Supply	100-240 V AC, 50-60 Hz
Card Feeding	Manual
