Evolis Pebble - Cards Loading; Card Feeder; Manual Feed Tray

9
Remove the feeder from
the printer as shown.
Replace the feeder in the
printer Then press on the
top of the feeder until it
clicks.
Press the spring system down
inside the feeder and insert
the cards as shown (100 cards
max. 0.76mm-30mil).
Note: The side to be printed
must be facing down.
CLIC
max.
max.
max.
max.
max.
Remove the
feeder from
the printer as
shown.
Using the lever, adjust
the thickness of the
card to MAX.
Insert the cards
as shown.
Manual feed tray (optional)
Card feeder
Place the
manual supply
tray in the
printer as indi-
cated. Then,
press on the
top of the tray
until it clicks.
CLIC
Cards loading
