MACHINE SPECIFICATIONS
MACHINE METRIC IMPERIAL
Motor (230-240V ~ 50 Hz) 1200W 5A
Motor (110V ~ 50 Hz) 1200W 11A
Speed No Load 3750 min
-1
3750 min
-1
Weight (Net) 5.8 kg 12.8 lb
Dust Port Diameter 35mm 1-3/8 In.
Tool Dimensions (H x W x L) (0° / 0°)
(Note: Dimensions taken with saw head down.)
260 x 393 x 381mm
10-15⁄64 x
15-15 ⁄ 32 x 15 In.
Cable Length 2m 6ft 9⁄16 In.
CUTTING CAPACITIES METRIC IMPERIAL
Mild Steel Plate - Max Thickness 6mm 1/4 In.
Mild Steel Box Section - Max Wall Thickness
(50mm mild steel box section.)
4mm 5/32 In.
Wood – Max section 125 x 55mm 4-15/16 x 2-3/16 In.
Minimum size work-piece
(Note: Any workpiece smaller than the recommended minimum
workpiece requires additional support before cutting.)
L:178 x W:20 x D:3mm 7 In.
MAXIMUM CUTTING ANGLES LEFT RIGHT
Mitre
50˚ at 0˚ Bevel
50˚ at 45˚ Bevel
50˚ at 0˚ - 20˚ Bevel
45˚ at 21˚- 45˚ Bevel
Bevel 0˚ - 45˚ N/A
MITRE BEVEL
MAX WIDTH
OF CUT
MAX DEPTH
OF CUT
0° 0° 125mm (4-15/16 In.) 55mm (2-3/16 In.)
0° 45° 125mm (4-15/16 In.) 35mm (1-3/8 In.)
45° 0° 85mm (3-3/8 In.) 55mm (2-3/16 In.)
45° 45° 85mm (3-3/8 In.) 35mm (1-3/8 In.)
BLADE DIMENSIONS METRIC IMPERIAL
Diameter 210mm 8-1/4 In.
Bore 25.4mm 1 In.
Thickness 1.7mm 1/16 In.
NOISE DATA
Sound Pressure L
P
A (No-Load) 110v: 96.02dB / 230v: 97.14dB
Sound Power Level L
W
A (No-Load) 110v: 109.02dB / 230v: 110.14dB
Uncertainty, K
pA
& K
WA
3 dB(A)
> The maximum permissible system impedance Zmax at the interface point of the user’s supply is 0,238. The user shall
determine in consultation with the supply authority, if necessary, that the equipment is connected only to a supply of that
impedance or less.
