Table Insert
A one piece table insert is tted to this
machine. If it is damaged or worn, it must be
replaced. Replacement inserts are available
from Evolution Power Tools.
Removing the Table Insert:
Note: Please ensure the machine is unplugged
from the mains supply before attempting to
remove the table insert.
• Position the saw at 0˚ bevel and 0˚ mitre.
• Places your ngers into the cutting gap of
the table insert and pull on the left side so
the table insert pops out of the xing slots.
• Continue to pop out the table insert from
all 4 sides.
Note: It may be necessary to temporarily
remove or reposition the fence to gain full
access.
• Once fully removed; clean away any debris
that may have accumulated under the
insert.
Replacing the Table Insert:
• Fit the replacement table insert back into
the xing slots allocated on all 4 sides.
• If necessary, replace and re-align the fence.
(see fence Alignment and Figs 12 & 13)
• Check that the insert is lying ush and level
within the table.
(6.1)
MAINTENANCE
Note: Any maintenance must be carried
out with the machine switched o and
disconnected from the mains/battery power
supply. Check that all safety features and
guards operating correctly on a regular basis.
Only use this machine if all guards/safety
features are fully operational. All motor
bearings in this machine are lubricated for life.
No further lubrication is required.
Use a clean, slightly damp cloth to clean
the plastic parts of the machine. Do not use
solvents or similar products which could
damage the plastic parts.
WARNING: Do not attempt to clean by
inserting pointed objects through openings
in the machines casings etc. The machines air
vents should be cleaned using compressed
dry air. Excessive sparking may indicate the
presence of dirt in the motor or worn out
carbon brushes.
(6.2)
If this is suspected have the machine serviced
and the brushes replaced by a qualied
technician.
(6.4)
ENVIRONMENTAL PROTECTION
Waste electrical products should not be
disposed of with household waste.
Please recycle where facilities exist.
Check with your local authority or retailer for
recycling advice.
