7. Drawings V10k automatic
52
EN
Injector 1" with accessory
Pos Part No. Description Quant.
1 W3T171367 Injector 1" PVC/PTFE/FPM 1
W3T171368 Injector 1" PVC/PTFE/FPM 1
2 Injector throat 1
3 Tailway 1
5 W3T170897 Clamping screw PVC 1
6 W3T159484 Adaptor nipple PVC;R1" x 1"NPT;80lg. 1
7 W3T163793 Adaptor union incl. o-ring
W3T172725
DN 25-R 1
d32,92x3,53
1
8 W2T506782 Reducing bush PVC;d32-25 1
9 W2T505893 Reducing bush PVC-U; d40-Rp1 1
10 W2T504882 Union incl. o-ring
W2T507049
PVC-U;d40;
d40,64x5,33
1
11 W2T505689 Reducing bush PVC-U;d32-Rp3/4 1
W3T163749 Adaptor union
incl. o-ring
W3T173010
DN 20-R 3/4
d28,17x3,53
1
W3T167396 Adaptor union incl. o-ring
W3T172725
DN25-R 3/4"
d32,92x3,53
1
W2T505689 Reducing bush PVC-U;d32-Rp3/4 1
12 W2T506786 Reduktion kurz PVC;d40-32 1
13 W2T504882 Union incl. o-ring
W2T507049
PVC-U;d40;
d40,64x5,33
1
14 W2T505446 Reducing bush d50+63-32+40 1
15 W3T167194 Reducing bush PVC, 1/2"NPT x DN 15 1
W3T172961 Threaded socket 1/4-18 NPT;d20;PVC 1
16 W3T161698 Clamping union 1/2-14NPT; 1
W3T171353 Clamping union for hose D3/8" d1/4" 1
W3T171372 Clamping union for hose 3/8 x 1/2" 1
20 W3T163614 Set of o-rings CSM 1
25 W3T171383 Fixing set 1
