V10k automatic 7. Drawings
55
EN
Pos Part no. Description Qty.
1 W3T169313 Body (5") PVC, V10k 1
W3T161817 Body (10") PVC, V10k 1
2+
19+60
W3T167495 Cover complete 1
3+4 W3T159801 Seat assembly PTFE; d6,7; above 3 kg/h 1
W3T171294 Seat assembly PTFE; d2,6; up to 2 kg/h 1
5-7 W3T167443 Valve stem complete 1
10 W2T507221 O-ring d5,28x1,78/CSM 1
11 W3T165515 Valve body assembly 1
12 W3T165176 Gasket PVC-P;D20,5 x 14,3x1 1
13 W3T161334 Gasket CSM;D32 x 25,4 x 3 2
14 W3T161294 Spring up to 60 g/h Cl2 1
W3T165193 Spring more than 60 g/h Cl2
15 W3T169056 Throttle plug PVC,Tr13/8"x8x38 (*W) 1
16 W3T161473 Hose connector PVDF,1/4-18 NPT-Id4xAd6 1
17 W3T168305 Gauge 0 mbar/Cl2/M14x1 1
18 W3T166236 Nut PVC-U, M14x1 1
20 W2T503950 T-Hose connector 18 NPT- Id 4 x Ad 6 (PVDF) 1
21 W3T171125 PTFE hose 230 lg 2
23 W3T168893 Plug PVC-U; 1/4-18NPT x 21 1
24 W3T168911 O-ring d16,6 x 5,1/FPM
2
25 Flowmeter see separate table 1
26 W3T169050 Base PVC; V10k 1
27 W3T161297 Spring 1
28 W3T164993 O-ring d20,22 x 3,53/CSM 2
29 W2T506920 Union nut PVC-U; d20 2
30 W2T507291 Union end PVC-U; d20 1
31 W2T506780 Reducing bush PVC; d20-16 1
32 W3T172961 Threaded insert 1/4-18 NPT; d20;PVC 1
33 W3T169110 Union PVC; 1/4NPT x 1/2-20UNF-2A 1
34 W3T169111 Union nut PVC; 1/2-20UNF-2B 1
35 W3T171126 Hose connector for hose RP-684821 1
36 W3T169009 Nut PVC 1
37 W3T165447 O-ring d12,37 x 2,62/CSM 1
38 W3T163379 Insert PVC 1
39 W3T168933 Support ring 0,8 thick 1
40 W3T167194 Reducing nipple PVC, 1/2"NPT x DN 15 1
41 W3T161698 Connector, male 1/2-14NPT 1
42 W2T507291 Union end PVC-U; d20 1
To Next Page
