7. Drawings V10k automatic
56
EN
43 W2T506780 Reducing bush PVC; d20-16 1
44 W3T172961 Threaded insert 1/4-18 NPT; d20; PVC 1
45 W3T169110 Union PVC;1/4NPT x 1/2-20UNF-2A 1
46 W3T169111 Union nut PVC; 1/2-20UNF-2B 1
47 W3T171126 Hose connector for hose RP-684821 1
48 W3T169009 Union nut PVC 1
49 W3T165447 O-ring d12,37 x 2,62/CSM 1
50 W3T163379 Insert PVC 1
51 W3T168933 Support ring 0,8 1
52 W3T167194 Reducing nipple PVC, 1/2" NPT x DN 15 1
53 W3T161698 Connector, male 1/2-14NPT 1
54 W3T165335 Plug GPN 620 U 10B 1
61 W2T507548 Name plate 68 x 35 1
95 W3T169846 Seal clamping screw PVC; 7/8-14NF x 23 1
96 W3T169197 O-ring d9,25 x 1,78/CSM 1
97 W3T170894 Shaft seal PTFE;D19/10,5; d8,9; x 4/0,8 1
98 W3T169844 Extension chamber PVC 1
99 W3T168909 O-ring d23,39 x 3,53/CSM 1
100 W3T161292 Orifice PTFE 1
101 V-notch plug linear see separate table 1
102 W3T168899 Washer d=12,7 x 4,9; PTFE 1
103 W3T163275 Stud Silver 1
104 W3T163273 Stem plug /D 1
105 W3T171121 Clamp-nut M20; PVC 1
106 W3T163456 Coupling Monel 400; 1/4-20 UNC 1
108 W3T172738 Hexagon nut PVC;1/4" 1
109 W3T171122 Guiding washer Id7,5 x Ad16,5; PVC 1
110 W3T173187 Positioner 230V; EU version 1
W3T173205 Positioner 115V; US version 1
111 W2T505723 Screw M5 x 50/DIN 7985/V2A 4
112 W2T506019 Washer DIN 125 A, 5,3 mm, A 2 4
235 W3T172956 Panel V10k 1
236 W3T165423 Washer DIN 9021-A - 5,3 - A2-70 3
237 W2T505771 Screw M5 x 20/DIN 7985/V2A 3
244 W2T504780 Anchor bolt M8 x 110, A2 4
245 W3T172730 Washer DIN 125 A, 8,4 mm, A 2 8
246 W2T507594 Dowel Nylon S 10 4
247 W3T172818 Nut DIN 934, M 8, A 2 4
248 W2T505532 Cap nut DIN 1587, M 8, Ms vern. 4
250 W2T505779 Plug GPN 500 B41; for M5 4
Pos Part no. Description Qty.
