Ewellix THG - Structure and Function; Telemag THG, TLG

10
THG/TLG/TLT
4.1 Telemag THG, TLG
Fig. 2
1. Upper attachment plate (optional)
2. Direction of motion when retracting
3. Direction of motion when extending
4. Transport screws
5. Jack plug connection cable
6. DIN-8 plug connection cable (optional)
4.0 Structure and function
7. Lower attachment plate (optional)
8. Lower base plate
9. Outer guide tube
10. Inner guide tube
11. Upper base plate
12. Middle guide tube
1
11
10
12
9
8
7
6
5
4
2 3
