4.0 Structure and function
4.9 Danger zones
4.9.1 Danger zone THG; TLG; TLT1
The following areas are dangerous:
• between the tube ends (2) and mounting plate (1)
in the completely retracted position.
• entire lift area between (1) and (3)
Fig. 8
Danger zones
1
2
3
4.9.2 Danger zone TLT2
The following areas are dangerous:
• between the tube ends (2) and mounting plate (1)
in the completely retracted position.
• entire lift area between (1) and (3)
• squeezingngersandsharpedges(1) and (2)
• electronic equipment (motor, printed cirquit boad and wir-
ing) (2) and (3)
• rotating elements (2) and (3).
Fig. 9
Danger zones
WARNING
• ForTLT2apreventionfromSqueezengersandaccessablero-
tating and electrical parts must be secured prior to use and oper-
ation.
• Cleaning is not allowed for electronic Equipment
• The TLT2 is not allowed to run into its mechanical end of travel
limits during normal operation.
• The TLT2 must only be operated with a suitable current limit
board.
1
2
3
