Excell SI-132 Service Manual

EXCELL PRECISION CO., LTD
02005302 ZSME300000237 14
2-1-1 Auto Backlight Function Setting
LCD displays the last status
Auto backlight function
When the weight is over 10d (d=division), the display backlight will be on.
After the weight is stable for 10 seconds or when the scale returns to zero, the
display backlight switches off.
Press TARE key
Use
ON/ZERO or UNITS key
to select function “on” or “of
f
Press
TARE key to go back
to the advanced function
setting menu
A
uto backlight function
On
Æ backlight function is on
Off
Æ backlight function is off

Excell SI-132 Specifications

General

Brand	Excell
Model	SI-132
Category	Scales
Language	English
