Excell SI-132 Service Manual

EXCELL PRECISION CO., LTD
02005302 ZSME300000237 33
Press TARE key
Refer to “Note 3”
Press
TARE key
Press TARE key
Refer to “Note 1”
Press
TARE key to
complete the setting.
Input the parameter “00
kg
Refer to “Note 2”
3-1-1 Weight Unit Setting
The weight UNITS ”kg, g, lb” have no resolution limit.
But the weight UNITS ”oz, GN, dwt, and ct” are only available on indicators with less 1/10,000
external resolution.
.
.
ON/ZERO key ⇒ Upward key (0~9 digit entry)
UNITS key ⇒ Downward key (0~9 digit entry)
TARE key ⇒ Move cursor rightward
NET/GROSS key ⇒ Move cursor leftward
The display shows new setting is max
capacity with 0.001 kg/division for 2
seconds. And back to the upper level.
The display shows current setting
is max capacity with 0.01kg/division
for 2 seconds.
Example:
Two weight UNITS “kg” & “lb”, with
“kg” as the UNITS used for weight
calibration.
Enter 015000 ⇒ 15.000 kg
Enter division (= m * 10
-n
*
q
) and segment
setting
1
⇒ base value (m) = 1
3
⇒ n = 3, 3 decimal point
2
⇒ 2 segment range
Press TARE key
